Bending Beam Load Cell WL-121 0.017% Accuracy 50-1000kg IP67

Features & Applications

The WL-121 is a bending beam load cell manufactured from stainless steel, designed for capacities ranging from 50kg to 1000kg with a maximum platform size of 800×1000mm. This bending beam load cell features compensated off-center load error, making it suitable for food, beverage, pharmaceutical, and other special fields, as well as belt scales, platform scales, and other electrical weighing devices. Different cable lengths and other options are available.

This bending beam load cell delivers a combined error of 0.017%F.S., non-linearity of 0.017%F.S., and repeatability of 0.01%F.S. Rated output is 2.0±0.002mV/V, zero balance is ≤1%mV/V, and insulation resistance is ≥5000MΩ/100VDC. With recommended excitation of 5~15 VDC, this sensor provides stable and repeatable measurements for demanding industrial environments.

The WL-121 offers IP67 protection as standard, with customizable higher ratings available. It operates within a wide temperature range of -40°C to 65°C. Nominal displacement varies by capacity: ≤250kg models have <0.4mm displacement, while 500~2000kg models have 1.4~1.5mm displacement. Standard cable is Φ6.3mm × 2500mm, with custom lengths available. Safe overload is 150%F.S., and the stainless steel construction ensures excellent corrosion resistance and durability for washdown environments.

Typical application:

• Food processing: checkweighing, batching, and filling on sanitary production lines

• Beverage industry: fill level verification for bottles, cans, and kegs

• Pharmaceutical manufacturing: dosing and quality control with washdown requirements

• Belt scales: continuous in-motion weighing for bulk materials

• Platform scales: general-purpose weighing up to 800×1000mm platform

• Specialized hygiene areas: applications requiring stainless steel and IP67 protection

Specifications

Dimensions(mm)

Load direction

Wiring code
