WL-121 – Stainless Steel Bending Beam Load Cell for Hygiene-Sensitive Industries

Name: WL-121 – Stainless Steel Bending Beam Load Cell for Hygiene-Sensitive Industries
Brand: Brans Measuring And Controlling Technology Co., Ltd
SKU: WL-121
Price: 25.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Brans

Model Number: WL-121

Document: WL-121 Bending Beam Load Ce...NS.pdf

Payment & Shipping Terms

Minimum Order Quantity: 1 pc

Delivery Time: one week

Payment Terms: T/T

Supply Ability: 800pcs/Month

Get Best Price

Product Details

Product Description

Highlight:

Capacity:	50/100/200/300/500/1000kg	Combined Error:	0.017%F.S.
Non-linearity:	0.017%F.S.	Repeatability:	0.01%F.S.
Rated Output:	2.0±0.002mV/V	Zero Balance:	≤1%mV/V
Insulation Resistance:	≧5000MΩ/100VDC	Material:	Stainless Steel
Safe Overload:	150%F.S.	Protection Class:	IP67 (Customizable)
Operation Temp.:	-40~65°C	Cable Size:	Ф6.3x2500mm (Customizable)

Capacity:	50/100/200/300/500/1000kg
Combined Error:	0.017%F.S.
Non-linearity:	0.017%F.S.
Repeatability:	0.01%F.S.
Rated Output:	2.0±0.002mV/V
Zero Balance:	≤1%mV/V
Insulation Resistance:	≧5000MΩ/100VDC
Material:	Stainless Steel
Safe Overload:	150%F.S.
Protection Class:	IP67 (Customizable)
Operation Temp.:	-40~65°C
Cable Size:	Ф6.3x2500mm (Customizable)

WL-121 – Stainless Steel Bending Beam Load Cell for Hygiene-Sensitive Industries

WL-121 – Stainless Steel Bending Beam Load Cell for Hygiene-Sensitive Industries

Product Description

- The WL-121 bending beam load cell is built from stainless steel and offers maximum capacities from 50kg to 1000kg. It features off-center load error compensation and supports platform sizes up to 800×1000mm, making it ideal for precision weighing in food, beverage, and pharmaceutical applications.

  Features & Applications
- Type: Bending beam load cell
- Material: Stainless steel
- Capacity range: 50kg – 1000kg
- Off-center load error: Compensated
- Max platform size: 800×1000mm
- Key applications: Food, beverage, pharmaceutical, and specialty industries
- Other uses: Belt weighers, platform weighers, and electrical weighing systems

Specifications

Capacity	50/100/200/300/500/1000kg
Combined Error	0.017%F.S.
Non-linearity	0.017%F.S.
Repeatability	0.01%F.S.
Rated Output	2.0±0.002mV/V
Zero Balance	≤1%mV/V
Insulation Resistance	≧5000MΩ/100VDC
Recommended Excitation	5~15VDC
Material	Stainless Steel
Safe Overload	150%F.S.
Protection Class	IP67(Customizable)
Operation Temp.	-40~65°C
Cable Size	Ф6.3x2500mm(Customizable)

Dimensions(mm)

WL-121 – Stainless Steel Bending Beam Load Cell for Hygiene-Sensitive Industries 1

Load direction

WL-121 – Stainless Steel Bending Beam Load Cell for Hygiene-Sensitive Industries 2

Wiring code

WL-121 – Stainless Steel Bending Beam Load Cell for Hygiene-Sensitive Industries 3

Shipping & Packaging

To ensure safe arrival at your location, the load cell will be carefully packaged and shipped. The packing process is as follows:

1. The load cell will be placed in a sturdy cardboard box to protect it from external damage during shipping.
2. The box will be filled with foam padding to provide additional cushioning and prevent the load cell from moving during shipping.
3. The load cell will be sealed in a plastic bag to protect it from moisture and other environmental factors.
4. Additional layers of bubble wrap will be provided for additional protection.
5. The carton is securely taped to prevent tampering.
6. A shipping label with your address and product information is attached to the box.
7. The package is shipped using a reliable and trusted freight carrier.

Once the package is shipped, you will receive a tracking number to monitor the status of your delivery. Please ensure that someone is available at the delivery address to receive the package to avoid any delays or problems.
