FD Series Platform Scales: Heavy-Duty Design for Demanding Environments

Name: FD Series Platform Scales: Heavy-Duty Design for Demanding Environments
Brand: Brans Measuring And Controlling Technology Co., Ltd
SKU: FD Series
Price: 750.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Brans

Model Number: FD Series

Payment & Shipping Terms

Minimum Order Quantity: 1 pc

Delivery Time: one week

Payment Terms: T/T

Supply Ability: 300pcs/Month

Get Best Price

Product Details

Product Description

Highlight:
                                                FD Series industrial platform scales, heavy-duty industrial weighing scales, platform scales for demanding environments


FD Series Platform Scales: Heavy-Duty Design for Demanding Environments

Features:

Sturdy construction with diamond-patterned steel or stainless steel surface and a U-shaped chassis.
Four high-precision load cells with IP67 (alloy steel) / IP68 (stainless steel) ratings.
Adjustable leveling feet.
IP66 stainless steel junction box.
6-digit, 20mm bright LED display with rechargeable battery (80+ hours).
RS232/485 communication ports for peripherals.
Three modes: weighing, counting, and accumulation.

Applications:

- Industrial and commercial weighing applications.
- Trade, logistics, and warehouse operations.
- Inventory counting and batch processing.

Dimensions:

FD Series Platform Scales: Heavy-Duty Design for Demanding Environments 0

Selection Table

Model	Dimensions (mm) AxBxH	Capacity(kg)	Division Value(kg)	Platform Material	Sensor Material	Signal Cable(m)	Net Weight(kg)	Part Number
FD0808-1t	800×800×90	1000	0.2	Carbon steel	Alloy steel	5	46	110808040210
FD1010-1t	1000×1000×90	1000	0.2	Carbon steel	Alloy steel	5	64	111010040215
FD1010-3t	1000×1000×90	3000	0.5	Carbon steel	Alloy steel	5	82	111010050330
FD1212-1.5t	1200×1200×90	1500	0.2	Carbon steel	Alloy steel	5	90	111212040215
FD1212-3t	1200×1200×90	3000	0.5	Carbon steel	Alloy steel	5	109	111212050330
FD1212 5t	1200×1200×90	5000	1	Carbon steel	Alloy steel	5	135	111212050450
FD1215-3t	1200×1500×90	1500	0.2	Carbon steel	Alloy steel	5	132	111215050330
FD1515-1.5t	1500×1500×90	1500	0.2	Carbon steel	Alloy steel	5	136	111515050215
FD1515-3t	1500×1500×90	3000	0.5	Carbon steel	Alloy steel	5	145	111515050330
FD1515 5t	1500×1500×105	5000	1	Carbon steel	Alloy steel	5	196	111515050450
FD1520-5t	1500×2000×105	5000	1	Carbon steel	Alloy steel	8	276	111520050450
FD2020-3t	2000×2000×90	3000	0.5	Carbon steel	Alloy steel	8	275	112020050330
FD2020-6t	2000×2000×105	6000	0.1	Carbon steel	Alloy steel	8	341	112020060460
FD2020-10t	2000×2000×140	10000	2	Carbon steel	Alloy steel	8	423	112020080401
FDS0808-1t	800×800×90	5000	0.2	Stainless steel	Stainless steel	5	47	120808040210
FDS1010-1t	1000×1000×90	1500	0.2	Stainless steel	Stainless steel	5	66	121010040210
FDS1010-2t	1000×1000×90	1500	0.5	Stainless steel	Stainless steel	5	75	121010050220
FDS1212-1.5t	1200×1200×90	3000	0.2	Stainless steel	Stainless steel	5	93	121212040215
FDS1212-3t	1200×1200×90	5000	0.5	Stainless steel	Stainless steel	5	113	121212050330
FDS1212-5t	1200×1200×105	5000	1	Stainless steel	Stainless steel	8	139	121212050450
FDS1215-1.5t	1200×1500×90	1500	0.2	Stainless steel	Stainless steel	5	115	121215040315
FDS1515-1.5t	1500×1500×90	1500	0.2	Stainless steel	Stainless steel	5	136	121515050215
FDS1515-3t	1500×1500×90	3000	0.5	Stainless steel	Stainless steel	5	145	121515050330
FDS1515-5t	1500×1500×105	5000	1	Stainless steel	Stainless steel	5	196	121515050450
FDS1520-5t	1500×2000×105	5000	1	Stainless steel	Stainless steel	8	276	121520050450
FDS2020-3t	2000×2000×90	3000	0.5	Stainless steel	Stainless steel	8	275	122020050330
FDS2020-6t	2000×2000×105	6000	1	Stainless steel	Stainless steel	8	341	122020060460

Shipping & Packaging

To ensure safe arrival at your location, the load cell will be carefully packaged and shipped. The packing process is as follows:

1. The load cell will be placed in a sturdy cardboard box to protect it from external damage during shipping.
2. The box will be filled with foam padding to provide additional cushioning and prevent the load cell from moving during shipping.
3. The load cell will be sealed in a plastic bag to protect it from moisture and other environmental factors.
4. Additional layers of bubble wrap will be provided for additional protection.
5. The carton is securely taped to prevent tampering.
6. A shipping label with your address and product information is attached to the box.
7. The package is shipped using a reliable and trusted freight carrier.

Once the package is shipped, you will receive a tracking number to monitor the status of your delivery. Please ensure that someone is available at the delivery address to receive the package to avoid any delays or problems.
