500g Load Cell Weighing Module Electromagnetic 5kg Load Cell
30g-6100g Electromagnetic Weighing Load Cell -WLDM-134
Overview:
working on the principle of electromagnetic induction,The WLDM--134 is electro-magnetic load cell for high precision weighing applications covering a weighing range from 30g to 6100g. Thanks to its integrated overload protection, the WLDM-134 is able to avoid euipment failure or misoperation damage. Because they are not impacted by changes in temperature or environmental conditions, they are ideal for use in demanding industries. The WLDM-134 comes in double capacity and accuracy with built-in RS232 communication interface, which enables direct connection with PLC and computer. The WLDM-134 finds applications in various industries, including manufacturing, automotive, aerosppace, and healthcare.
Features :
1. The best option for quick manufacturing procedures
2. Adaptable and simple integration thanks to a strong mechanical structure, dependable overload safety, and supplementary, adjustable dead load range
3. Automatic dual precision and range settings
4. The purpose of manual external calibration
5. The ability to adjust temperature in real time
6. An anti-static and anti-interference aluminum shell
7. A huge LCD interface display
8. Modifiable stability time for weighing
9. Different shielding units, include milligrams, ounces, and grams
10. The machine is currently locked on or off automatically.
11. An changeable built-in temperature, date, and time display feature
12. After installing the plug-in, the PC's balance data can be read immediately.
13. Provided with an RS232 connection for connecting auxiliary devices
Dimension(MM):
Specifications:
| Capacity(g) |
Readability(mg) |
repeatability(mg) |
Linearity(mg) |
|
30
|
0.01 |
±0.03 |
±0.03 |
| 50 |
0.01 |
±0.03 |
±0.03 |
| 80 |
0.01 |
±0.03 |
±0.03 |
| 100 |
0.01 |
±0.03 |
±0.03 |
| 110 |
0.1 |
±0.1 |
±0.2 |
| 210 |
0.1 |
±0.1 |
±0.2 |
| 300 |
0.1 |
±0.2 |
±0.3 |
| 400 |
0.1 |
±0.2 |
±0.3 |
| 500 |
0.1 |
±0.2 |
±0.3 |
| 210 |
1 |
±1 |
±2 |
| 510 |
1 |
±1 |
±2 |
| 1000 |
1 |
±2 |
±3 |
| 1200 |
1 |
±2 |
±3 |
| 2000 |
1 |
±2 |
±3 |
| 3000 |
1 |
±2 |
±3 |
| 1100 |
10 |
±10 |
±20 |
| 2100 |
10 |
±10 |
±20 |
| 3100 |
10 |
±10 |
±20 |
| 4100 |
10 |
±10 |
±20 |
| 5100 |
10 |
±20 |
±20 |
| 6100 |
10 |
±20 |
±30 |
Data Acquisition:
