30 Ton Load Cell Manufacturer Flange To Flange Compression Load Cell

Flange to Flange Heavy Duty Compression Load Cell 5t, 10t, 20t, 30t, 50t-CF-811

Product Description:

Based on well-developed strain gauge technology, the CF-811 covers a high capcaity range from 5T to 50T for heavy duty force measuring in compression applications. The CF-811 has flange structure on both sides for easy installation. This flange type compression load cell is commonly used in a wide range of applications from punching equipment, impact testing quipment, pneumatic hydraulic euipment. The rugged design, small deflection, and high dynamic response frequency makes the high accurate and reliable measuring data possible.

Brans are always devoted to delivering satisfied and favourable services to each our clients to meet their specific needs. We deeply understand that each apllication is different and requires a customized response.

To make sure providing the best solution, the load cell can be adapted to meet customer requirements.


Features&Applications:

• Flange type compression force sensor
• Small deflection and plane mountable
• High dynamic response frequency
• Load range: 5t- 50t
• Made of stainless steel
• Different cable lengths,capcities, dimensions are optionally available
• Mainly used for punching equipment, impact testing euipment, pneumatic hydraulic euipment

Specifications:

Dimension(MM):

Load Direction:

Wiring:

Load Cell Packaging and Shipping

To ensure safe arrival at your location, the load cell will be carefully packaged and shipped. The packing process is as follows:

1. The load cell will be placed in a sturdy cardboard box to protect it from external damage during shipping.
2. The box will be filled with foam padding to provide additional cushioning and prevent the load cell from moving during shipping.
3. The load cell will be sealed in a plastic bag to protect it from moisture and other environmental factors.
4.  Additional layers of bubble wrap will be provided for additional protection.
5. The carton is securely taped to prevent tampering.
6. A shipping label with your address and product information is attached to the box.
7. The package is shipped using a reliable and trusted freight carrier.

Once the package is shipped, you will receive a tracking number to monitor the status of your delivery. Please ensure that someone is available at the delivery address to receive the package to avoid any delays or problems.
