Load Cell Accuracy Class C2 Small Load Cell 5kg 10kg 20kg 30kg

1kg To 30kg Analog Single Point Load Cell With Compact Structure And High Precision -WL-119

Product Description:

The side-mounted single point load cell WL-119 is designed for uses requiring a weight range of 1 kg to 30 kg. The weight sensor WL-119 performs its weighing duties with exceptional stability and high precision by utilizing strain gauge technology. The platform size can be up to 200mm*200mm and it is intended for dynamic weighing applications with a compact structure. The right side of the load cell is screwed into place solidly, while the opposite side is loaded. Furthermore,The load cell WL-119 is available in three different dimensions (please refer to the photographs below for an example). Its potential uses include food packing machines, electronic scales, auto filling machines, and more.


Brans are always devoted to deliver satisfied and favourable services to each our clients to meet their specific needs. We deeply understand that each apllication is different and requires a customized response.

To make sure providing the best solution, the single point load cell can be adapted to meet customer requirements.

Features and Applications:

• Side mounted single point load cell for 1kg to 30kg
• Aluminum alloy construction:side mounted configuration.
• High and long term stability;support for dynamic weighing
• With compact structure ,easy to install
• Ideal for all OEM applications
• Max.platform size up to 200mm×200mm
• three different dimensions available
• Mainly used for food packaging machines,electronic scales,auto filling machines

Specifications:

Dimension(MM):

                                4/5/6/8/10/20/30kg

                                                    1/2/3/5kg

                                 10/15/20/30kg

Load Direction:

Wiring:
